Dacron, woven polyester sailcloth 170 MT, 170g/sqm

Article No.: 71605.SW

€25.90/meter

incl. 19 % VAT plus

Please select your variant:

Choose a color

When folding the fabric it will get permanent folding marks. 0,5m will be shipped rolled in a carton. To prevent folding marks on bigger orders, we can ship the fabric on the roll. If you want to receive your order on the roll, please choose the option "Shipping on the roll" during the checkout-process.

In stock.  Deliverable between 2-4 days

Meter

Product information

Dacron, woven polyester sailcloth 170 MT, 170g/sqm

Original Dacron polyester, specially designed for our kite, sail, and kiteboarding customers. Dacron Surf Polyester 170 MT from Dimension Polyant is a woven canvas made from the brand-name fiber Dacron. It consists of densely woven polyester fibers that are fixed with resin, tempered, and sealed with a coating. This creates a fabric with very high tear resistance, abrasion resistance, and dimensional stability, as well as excellent UV and weather resistance. The fibers do not absorb moisture, which means that the fabric does not stretch and dries extremely quickly. Due to its construction and finish, the fabric has the firm, slightly stiff feel typical of Dacron and is completely windproof, but not waterproof.

Dacron is manufactured in many different versions, and this variant is particularly suitable for the following uses:

- Kites for kitesurfing: Many kite manufacturers use Dacron 170 MT for its quality and durability for leading edges, struts, and reinforcements of kite sails. The high pressure in the inflated tubes, frequent and sometimes violent contact with the ground and water, intense UV radiation, and transport tightly folded in a backpack place enormous demands on the quality of the material. It is suitable without restriction for the repair and self-construction of tube kites.

- Kites: Whether for stick kites, box kites, stunt kites, single-line kites, or two-line kites, Dacron can be used as a reinforcement material for areas subject to heavy wear.

- Windsurf sails: In combination with transparent monofilm or X-Ply, 170 MT Dacron can be used to manufacture high-quality windsurf sails. It is also very well suited for repairs or reinforcements on windsurf sails.

- Hang gliders and ultralight aircraft: For hang gliders, Dacron 170 MT can mainly be used for the leading edge, the sail, batten pockets, and reinforcements. For ultralight aircraft and trikes, you can use it to cover the wings and fuselage.

- Sails: As classic sailcloth, it can be used for the sails of smaller boats ( jollyboats, Optimists, Lasers, etc.) and as a genoa or jib (headsail). The 170 MT can also be used to make very good and colorful sails for beach sailboats. The typical cut is crosscut.

- Bags: Canvas bags do not always have to be made by upcycling or recycling old sails. Our Dacron is also ideal for this purpose. Unlike other fabrics such as Cordura or X-Pac, Dacron is stiffer, so even an empty bag retains its shape. Nevertheless, the fabric is flexible enough to allow the bag to be folded. With its lower weight, Dacron is also an alternative to the truck tarpaulin often used for sling bags.



Short info

Range of Application
Kite/Sail
Properties
Windproof, low stretch
Stock Options
Standard Article
Country of Origin
Germany
Processing instructions
As is usual with woven polyester fabrics, the number of weft threads is higher than that of warp threads. The tensile strength is therefore higher across the direction of travel (weft) than in the warp direction. The elongation is greatest diagonally to the fiber direction; high forces should be avoided in this direction. Despite the coating, open and visible cut edges should be sealed with a hot cutter or additionally edged to prevent fraying over time. 170 Color MT Dacron can be processed very well with double-sided adhesive tape and can be permanently painted or printed with many colors. With a household sewing machine, 3-4 layers can be sewn together without any problems. Due to its stiffness, Dacron 170 MT is only suitable for clothing to a limited extent.

Technical Informations

Roll Width
1440mm
Weight (g/sqm)
170g/sqm
Material
Polyester (PES), 100% polyester
Coating
MT (melamine based impregnation)
Fabric Construction
Taffeta
