ECOPAK® EPX200, recycling-backpack-laminate, 200g/sqm

Article No.: 72449.DPPRPL

€33.40/meter

incl. 19 % VAT plus

Please select your variant:

Choose a color

matching yarn: article 70009 purple

When folded for shipping the laminate will get permanent folding marks. This does not affect the technical properties. If you wish to receive the material without folding marks, please choose "shipping on the roll" during checkout.

In stock.  Deliverable between 2-4 days

Meter

Product information

ECOPAK® EPX200, recycling-backpack-laminate, 200g/sqm

ECOPAK™ by Challenge Sailcloth is a backpack laminate made from 100% recycled polyester. Similar to a sailcloth laminate, this fabric laminates an outer fabric together with a UV-stable, highly waterproof polyester film or ripstop polyester. The strong, blue CrossPly polyester fibres lying in a diamond shape between the layers increase the tear resistance and prevent the material from stretching in all directions. In addition, the CrossPly fibres give ECOPAK™ its typical, technical look. In the EPLX versions, the smooth film is on the inside; in the EPX styles, a lining of 70den ripstop polyester has been laminated on. This lining additionally reinforces the fabric, e.g. at particularly stressed seams, and ensures a light interior in backpacks and bags. The area of use is determined by the strength of the outer fabric and the associated abrasion and tear resistance.

In developing ECOPAK™, Challenge Sailcloth focused on sustainability in addition to performance:

- All components of the ECOPAK™ laminates are made from 100% recycled polyester. This means that metre for metre, over 20 plastic bottles are recycled and more than 450g of carbon dioxide is saved.

- The outer fabric is made from REPREVE® yarns collected in the ocean, all other components are made from used PET bottles

- Only FC-free C0 impregnations are used.

- No VOCs (Volatile Organic Compounds) are used in the production of ECOPAK™, all adhesives are solvent-free

- Thanks to an innovative production process, energy-intensive drying processes during lamination are reduced

- ECOPAK™ lies very flat when cut and has a very uniform CrossPly fibre from edge to edge - this prevents waste when cutting to size

- The polyester outer fabric used is similarly abrasion resistant to fabric made of nylon and is therefore very durable

- Because ECOPAK™ is made from 100% polyester, it is recyclable

ECOPAK™ EPX200 combines a 200den recycled polyester with a 70den ripstop lining. In between, at a 45° angle, are the blue CrossPly fibres. EPX200 is a good choice for small to medium sized backpacks, EPX400 or EPX600 is recommended for floorboards and high abrasion areas.



Short info

Range of Application
Backpack/Bag
Properties
Waterproof (over 5000mm), Windproof, Quick Drying, Ultralight, Highly Abrasion-Resistant, Inelastic, FC-Free Impregnation, Recycling, PFC-free C0 impregnation
Stock Options
Standard Article, Whole Rolls available from Stock
Country of Origin
China
Colour
Outer as options, back with whiteish-transparent ripstop-lining with visible, blue CrossPly-threads
Care instruction:
Ecopak® should not be machine-washed or tumbled since this will cause delamination. Clean it with soft cloth or sponge and mild saop or water only and let it dry in the air.

Technical Informations

Roll Width
1420mm
Weight (g/sqm)
200g/sqm
Material
Polyester (PES), 200den polyester outer fabric, CrossPly-threads made of polyester, distance app. 17mm, lining made of 70den Recycling-Polyester
Coating
Membrane
Impregnation
FC-free C0 Impregnation
Fabric Construction
Taffeta, Laminate
Certificate
Bluesign-certification is in progress
Weight
200,1g/qm bzw. 5,9oz/sqyd
Tear Strength Warp/Fill (ASTM D2261)
26,7lb / 24,8lb
Hydrostatic head (psi/bar)
200+/13,8+
Abrasion (ASTM 3884)
500 cycles
